Diamond-Coated Super Hard D-GDN
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Hole diameter (drill diameter) Dc (mm) | Groove Length L (mm) | Overall Length L (mm) | Shank Type | Shank diameter (mm) | Tool No. | |
|---|---|---|---|---|---|---|---|---|---|---|
94.07 € | 1 | 6 Days | 2 | 18 | 54 | End Mill Shank | 3 | 8601020 | ||
104.08 € | 1 | 6 Days | 2.3 | 20 | 54 | End Mill Shank | 3 | 8601023 | ||
104.08 € | 1 | 6 Days | 2.5 | 22 | 54 | End Mill Shank | 3 | 8601025 | ||
102.92 € | 1 | 6 Days | 3 | 25 | 59 | Straight shank | 3 | 8601030 | ||
106.71 € | 1 | 6 Days | 3.3 | 27 | 59 | End Mill Shank | 4 | 8601033 | ||
106.71 € | 1 | 6 Days | 3.5 | 30 | 65 | End Mill Shank | 4 | 8601035 | ||
108.88 € | 1 | 6 Days | 4 | 33 | 65 | Straight shank | 4 | 8601040 | ||
130.54 € | 1 | 6 Days | 4.2 | 33 | 73 | End Mill Shank | 5 | 8601042 | ||
130.54 € | 1 | 6 Days | 4.5 | 36 | 73 | End Mill Shank | 5 | 8601045 | ||
135.96 € | 1 | 6 Days | 5 | 39 | 73 | Straight shank | 5 | 8601050 | ||
167.92 € | 1 | 6 Days | 5.5 | 43 | 80 | End Mill Shank | 6 | 8601055 | ||
167.92 € | 1 | 6 Days | 6 | 43 | 83 | Straight shank | 6 | 8601060 | ||
203.12 € | 1 | 6 Days | 6.5 | 47 | 87 | End Mill Shank | 7 | 8601065 | ||
224.79 € | 1 | 6 Days | 6.8 | 50 | 90 | End Mill Shank | 7 | 8601068 | ||
224.79 € | 1 | 6 Days | 7 | 50 | 90 | Straight shank | 7 | 8601070 | ||
239.96 € | 1 | 6 Days | 7.5 | 52 | 92 | End Mill Shank | 8 | 8601075 | ||
254.58 € | 1 | 6 Days | 8 | 56 | 96 | Straight shank | 8 | 8601080 | ||
267.04 € | 1 | 6 Days | 8.5 | 56 | 96 | End Mill Shank | 9 | 8601085 | ||
278.42 € | 1 | 6 Days | 9 | 61 | 101 | Straight shank | 9 | 8601090 | ||
289.25 € | 1 | 6 Days | 9.5 | 61 | 105 | End Mill Shank | 10 | 8601095 | ||
299.00 € | 1 | 6 Days | 10 | 65 | 109 | Straight shank | 10 | 8601100 | ||
307.67 € | 1 | 6 Days | 10.3 | 65 | 109 | End Mill Shank | 11 | 8601103 | ||
307.67 € | 1 | 6 Days | 10.5 | 65 | 109 | End Mill Shank | 11 | 8601105 | ||
316.33 € | 1 | 6 Days | 11 | 71 | 115 | Straight shank | 11 | 8601110 | ||
324.46 € | 1 | 6 Days | 11.5 | 71 | 121 | End Mill Shank | 12 | 8601115 | ||
330.42 € | 1 | 6 Days | 12 | 76 | 126 | Straight shank | 12 | 8601120 |
Loading...
Basic information
| Work material | Aluminum / Copper | Tool Material Type | Carbide | Coating Y/N | Available |
|---|---|---|---|---|---|
| Coating Type | Dia Coat | With/without Oil Hole | N/A | Tip angle(°) | 120 |
| Thinning | Available |
Configure
Basic Attributes
-
Hole diameter (drill diameter) Dc(mm)
-
Groove Length L(mm)
-
Overall Length L(mm)
-
Shank Type
- End Mill Shank
- Straight shank
-
Shank diameter(mm)
-
Tool No.
-
Type
- D-GDN
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
